DYNASCAN L44 PLUS Ref 2044

Dynascan L44 PLUS

€59.00
Tax included
DYNASCAN L44 PLUS PMR

SPECIFICATIONS


  • Frequency range: 446.00625 MHz to 446.09375 MHz.
  • Command Voice programmable information.
  • 50 Programmable CTCSS Sub tones and 83 DCS Codes.
  • VOX Programmable Functions. Transmission activated through voice (Hand-free function).
  • TOT Function. Transmission programmable timer.
  • BCL Function. Programmable Busy Channel Lock.
  • Programmable Scan Function.
  • FM comercial radio reception.
  • Programmable Battery Save Function.
  • Possibility of power regulation from 500mW to 100Mw to save battery energy and maximize the charge.
  • Emergency Call Function.
  • Channel Lock Function .Frequency range:  446.00625 MHz – 446.09375 MHz (Rx/Tx).
  • Channels:   16 (8+8).
  • Channeling: 12.5 kHz.
  • Modulation: 8K5F3E (FM).
  • Working temperature:   -20 ºC to +55 ºC.
  • Power supply: Li-Ion rechargeable battery, 7.4 Vdc / 2300 mAh.
  • Consumption: 15 mAh (With battery saver function).
  • Antenna:  Integral.
  • Dimensions (mm): 100 (H) x 58 (W) x 36 (D).
  • Weight (g): 205 (approx.)
  • Working cycles:   3-3-54 minutes (Tx-Rx-Standby).

 Transmission

  • Output power (P.R.A.): 500 mW (max)
  • Frequency stability:  ±3 ppm.
  • Consumption: ≤1.5 A.
  • Max. Deviation: ≤±2.5 kHz.
  • Distortion: <10 %.
  • Adjacent cannel power:<70 dB.
  • Spurious emissions: <-60 dB

Reception

  • Sensitivity:<-122 dBm (12 dB SINAD).
  • Squelch sensitivity:<-126 dBm.
  • Audio Output:500 mW
  • Consumption:≤380 mA.
  • Distortion:<10 %.
  • Adjacent channel selectivity: ≥60 dB.
  • Intermodulation:≥60 dB.
