ESVA-2K

ESVA 2 K

€4,250.00
Tax included

Suono Telecom ESVA-2K FM Broadcast Transmitter 2 kW Mono/Mpx

Suono Telecom ESVA-2K

Broadcast FM Transmitter mod. ESVA-2K



  • Compact 3HE professional case
  • Lower AC power consumption and Lower heating
  • Top sound quality due to an FM signal generator having excellent signal/noise ratio and ultralow THD
  • Full Broadband. No tuning or adjustments required.The frequency can be easily changed in whole FM band
  • Use of last generation LDMosFet’s for top-energy saving
  • Dynamic protection of the power output which is automatically reduced to keep your station on the air
  • Wide operating voltage range: 100-240V AC with high efficiency Power Supply
  • Easy and intuitive way to change frequency under a password key
  • Simple installation and setup

Technical features:

Frequency Range: 85 ÷ 108 MHz

Type: Full Solid State Mos-Fet-Wide Band

Modulation: FM

Emission Class: F3E

VCO Tuning: 25 MHz

Frequency Stability: ± 2.5 ppm

Synthesizer Step: 100 KHz (10 KHz on request)

Power Output: 0 ÷ 2000 W

Spurious Emission: < - 80 dB or better

Harmonic Emission: < - 60 dB

Stereo Separation: > 55 dB @ 1 KHz

Distortion: < 0.1 % (TYP. 0.06%) @ 1 KHz

Base Band: 30 Hz ÷ 60 KHz within 0.15 dB

Unweighted S/N Ratio: > 80 dB (30Hz ÷ 15KHz 50μS RMS)

Asyncronous AM S/N Ratio: > 65 dB Ref. 100% AM 400 Hz

Syncronous AM S/N Ratio: > 65 dB with FM @ 75 KHz @ 400 Hz

Pre-Emphasis: 50 or 75 μS int. selectable

RF Out Connector: 7/16" Female

MPX Input Connector: BNC-F

MPX Input Impedance: 2 KOhm

SCA Input Connector: 3 BNC-F

Protections: Overload, Temperature, VSWR in a fold-back reducing power

Cooling: Forced air

Op. Temperature Range: 0 ÷ +50 °C

Maximum Umidity: 95 % non condensing

AC Supply: 110 ÷ 264 VAC - 47 ÷ 63 Hz

Dimension: 3 unit rack 19", 530 mm depth

Weight: 18 kg

Download

ESVA-2K

Download (1.84MB)
