Easy to operate The TRI is a powerful tuning aid that, together with the automatically controlled input attenuator, helps the operator to quickly and precisely match the antenna impedance to the optimum tube load impedance (5-10 seconds typically). The auto-operate function (when enabled) maintains the amplifier in the OPERATE mode for you, thus avoiding unnecessary manual operations.
Intermodulation Distortion: Better than 35dB below rated
output.
Hum and noise: Better than 40dB below rated output.
Harmonic Output Suppression:
-1.8-21.5MHz - better than 50dB below rated output; - 24-54MHz - better than 66dB below rated output.
Input and Output Impedances:
- nominal value: 50 Ohm unbalanced, UHF (SO239) type connectors; - input circuit: broadband, VSWR less than 1.3:1, 1.8-54MHz continuously (no tunings, no switching); - bypass path VSWR less than 1.1:1, 1.8-54MHz continuously; - output matching capability: better than VSWR 3:1 or greater at reduced output levels.
RF Gain: 13dB typically, frequency response less than
1dB (60-85W drive power for rated output).
Primary Power: 85-132V and 170-264V (100, 110, 120,
