Mechanical Data:
| Materials: |
Aluminium, Copper, Brass, Galvanized steel, Nylon |
| Height (approx): |
6100 mm / 20.01 ft |
| Weight (approx): |
5300 gr / 11.68 lb |
| Mounting type: |
On-Mast |
| Type: |
5/8 λ ground plane |
| Radiation: |
Omnidirectional |
| Polarization: |
Linear vertical |
| Frequency range: |
26.4 ... 28.2 MHz Tunable |
| Systems: |
10m-HAM |
| Gain: |
1.3 dBd, 3.45 dBi |
| Bandwidth: |
- SIRIO 2008:
- ≥ 1.75MHz @ SWR ≤ 2
- SIRIO 2016:
- ≥ 2.1MHz @ SWR ≤ 2
|
| Max Power: |
1000 Watts (CW) continuous
3000 Watts (CW) short time |
| Grounding protection: |
DC-Ground |
| Connector: |
UHF-female (SO-239) |
http://www.sirioantenne.it/en/products/hf/sirio-2000-series
