Mechanical data
- Materials: Aluminnum Alloy AW6063-T66 hard drawn tube, Fiberglass, Brass, PTFE. All hardware are made of SS AISI-304 and 316
- Mast Ø: 40 - 54 mm
- Max wind resistance: 150 km/h
- Height: 4170 mm (including bracket)
- Weight: 3340 gram
- Mounting type: On mast
- Antenna connector: UHF-female, PTFE insulator & gold plated central pin
- Radial length: 1400 mm
16 meer producten uit dezelfde categorie:
Electrical data
- Electrical type: 5/8 λ VHF GP
- Gain: 1.50 dBd - 3.65 dBi
- VSWR: ≤1.2:1
- Bandwidth: ≥ 3.1 MHz at 50 MHz
- Maximum continuous power: 2000 Watts (CW)
- Impedance: 50 Ohm
- Polarization: Linear vertical
- Feed system: High “Q” air wound matching coil, DC-Ground
