SPECIFICATIONS

MAIN FUNCTIONS

• Frequency range: 144 - 146MHz (136-174 modificatie)
• Power supply: 60 W
• 200 Programmable memories and alpha-numerical characters
• CTCSS/DCS/5 Tones Encoding and Decoding
• CTCSS/DCS Tone Scanner
• Compander Function (noise reduction)
• Anti-theft Alarm
• ANI Function. DTMF/ANI, 5 tone/ANI PTT ID
• Microphone with DTMF keyboard included
• Built-in Scrambler Function
• Programmable by PC
• Channel spacing: 25 kHz / 20 kHz / 12.5 kHz
• Antenna impedance: 50 Ohm
• Channel steps: 5kHz, 6,25 kHz, 8,33 kHz, 10 kHz, 12,5 kHz, 15 kHz, 20 kHz, 25 kHz, 30 kHz and 50 kHz
• Power voltage: 13.8 V
• RF Power: 60W/25W/10W
• Working temperature: from -20º C to + 60º C
• Dimensions (approx): 145 mm (W) X 27 mm (H) X 190 mm (D)
• Weight (approx): 1.2 Kg.
• Vehicle mounting included.
