SPECIFICATIONS

• Frequency range: 446.00625 MHz to 446.09375 MHz.
• Command Voice programmable information.
• 50 Programmable CTCSS Sub tones and 83 DCS Codes.
• VOX Programmable Functions. Transmission activated through voice (Hand-free function).
• TOT Function. Transmission programmable timer.
• BCL Function. Programmable Busy Channel Lock.
• Programmable Scan Function.
• FM comercial radio reception.
• Programmable Battery Save Function.
• Possibility of power regulation from 500mW to 100Mw to save battery energy and maximize the charge.
• Emergency Call Function.
• Channel Lock Function .Frequency range:  446.00625 MHz – 446.09375 MHz (Rx/Tx).
• Channels:   16 (8+8).
• Channeling: 12.5 kHz.
• Modulation: 8K5F3E (FM).
• Working temperature:   -20 ºC to +55 ºC.
• Power supply: Li-Ion rechargeable battery, 7.4 Vdc / 2300 mAh.
• Consumption: 15 mAh (With battery saver function).
• Antenna:  Integral.
• Dimensions (mm): 100 (H) x 58 (W) x 36 (D).
• Weight (g): 205 (approx.)
• Working cycles:   3-3-54 minutes (Tx-Rx-Standby).

 Transmission

• Output power (P.R.A.): 500 mW (max)
• Frequency stability:  ±3 ppm.
• Consumption: ≤1.5 A.
• Max. Deviation: ≤±2.5 kHz.
• Distortion: <10 %.
• Adjacent cannel power:<70 dB.
• Spurious emissions: <-60 dB

Reception

• Sensitivity:<-122 dBm (12 dB SINAD).
• Squelch sensitivity:<-126 dBm.
• Audio Output:500 mW
• Consumption:≤380 mA.
• Distortion:<10 %.
• Adjacent channel selectivity: ≥60 dB.
• Intermodulation:≥60 dB.
