Compatible with Motorola Tier I & II and Hytera DMR radios Digital protocol ETSI TS 102 361-1, -2, -3 TDMA Digital Protocol ETSI TS 102 361-1, -2, -3
Description of Features:- English Voice Guide
- Power Save
- VOX Function
- Transmit Overtime Forbidden
- Inner Microphone Gain
- Low Voltage Voice Prompt
- SOS Alarm
- ANI ID
- Scan Group Setting
- Scan Channel Selection
- Digital Encryption
- LED Flash light
- Multi-Function Program for Side keys
- One Key Switch Digital / Analogue Mode
- One Key Switch High / Low Power
- PTT ID
- English Typewriting
- Contact Edit
- English Menu
- Remote Control
- Remote Monitor
- MSG Send and Receive
- Intelligent Charger
Product Specifications:
Integral part
- Mode: DMR
- Frequency Range: 400-470MHz
- Channel Spacing: Digital : 12.5KHz
- Channel number: 1024
- Zones: 64x
- Standard Package: 2000mAh , Lithium-ion
- Working temperature: -20℃~+50℃
- Storage temperature: -40℃~+80℃
- Working Voltage: 7.4VDC
- Working Currency: < 1300mA
- Weight: 261 g
- Size: 65 x 33 x 124 (mm)
Receiver
- Frequency Stability: ±2.5ppm
- Inter-modulation: 65dB
- Co-channel Rejection: -8dB@12.5KHz
- Spurious Inhibition: -57dBm@<1GHz , -47dBm@>1GHz
- Block: 84dB
- Adjacent Channel Selectivity: 60dB@12.5KHz
- Spurious Response: ≥70dB
- Regulated Audio Power: 1W
- Digital Sensitivity: 0.3µV / -117.4dBm(BER 5%) , 0.7µV / -110dBm(BER 1%)
Receiver (wide/narrow)
- Transmission Power: ≤5W
- FM Noise: 40dB@12.5KHz
- Transmission Spurious: -36dBm@<1GHz , -30dBm@>1GHz
- Adjacent Power: -60dB@12.5KHz
- Bandwidth Limit: 2.5KHz@12.5KHz
- Spare Time Slot Power: -57dBm
- Modulation Characteristics: +1dB~-3dB
- Digital Transmission Bit Error Rate: ≤3%
- Output Power: ≤5W
- 4FSK Digital Modulation Method: 12.5KHz(data only):7K60FXD
12.5KHz(data+voice):7K60FXE
