General
Power Range…                         0.1W to 5KW PEP / 2500W Average
Absolute Power Accuracy…      Better than 5% at 14 MHz, NIST traceable.
                                              (Reduced accuracy below 5W)
Flatness…                               Better than +/- 3% from 1.8 to 54 MHz
                                               (+/- 1% dB typical from 1.8 to 30 MHz)
Directivity...                              >30 dB, 1.8 to 54 MHz
Return Loss...                           >40 dB, 1.8 to 54 MHz
SWR Range…                          1.00 to 9.99
SWR Accuracy…                      5%
Bar Graph Resolution...             600 steps for each range, Manual or Auto-Ranging
Number of Channels…               8 simultaneous (FWD & REF power for 4 couplers)
Channel Balance...                    +/- 0.1%
Memories...                              Range & Alarm settings are saved per channel
                                               Channel settings are saved per mode
A/D Converter                          16-bit / 200ksps, plus oversampling (2X to 16X).
DAC Resolution…                    18-bit, 96 dB SNR
Screen Refresh…                      5 Hz to 70 Hz, depending on mode, sweep/span settings.
Sampling Rate…                       2.5k to 80 ksps, depending on mode, sweep/span settings.
Display Resolution                    800 x 480 pixels (WVGA)
Display Type                            TFT with White LED Backlight
Display Size                            LP-500: 5" Diagonal, LP700:  7" Diagonal
Test Tone Output…                  250 ohms, 350-500mVpp, unbalanced, 0.01% THD into 10K load
Power Requirements…             12-16VDC @ 800 mA maximum
Size…                                     LP-500: 9.125"W x 6.1"D x 4.88"H (23.2cm x 15.5cm x 12.4cm)
                                                              LP-700: 10.125"W x 6.1"D x 5.63"H (25.7cm x 15.5cm x 14.3cm)
Scope
Sweep Rate …                         1.0 to 20.0 ms/division in 0.1 ms steps
                                               5 Factory Presets and 3 User Adjustable Presets
Display Modes …                     7, including 4 split screens
Trigger Modes …                      Normal, Plus, Minus, Plus/Minus, Free Running.
AM Modulation % …                 0 to 150, positive. 0 to 100 negative.
Cursors …                               2, measuring peak voltage and time (ms)
Markers...                                1 or 2, adjustable to show preset power limits

Spectrum
Frequency Spans...                  2.5, 5.0 & 10.0 kHz, w/linear or log scaling
Span Multiplier...                      5X (500 & 1000 Hz, linear)
RBW…                                   1 to 20 Hz, depending on span
Averaging…                             2X to 16X
Full Scale Reference…             +45, +55, +65 dBm
ADC Dynamic Range…            > 90 dB
Coupler Dynamic Range...        Up to 80 dB, depending on modulation type
Cursors …                               2, measuring peak power (dBm) and frequency (Hz)
Markers...                                1, adjustable to show preset power limit

Additional Couplers

LPC-502
Range...                                   5KW PEP / 2500W average
Flatness...                                Better than +/- 3% from 1.8 to 54 MHz
                                                (+/- 1% typical from 1.8 to 30 MHz)
Directivity...                              >30 dB for 1.8 to 54 MHz
Return Loss...                           >40 dB from 1.8 to 54 MHz

LPC-503
Range...                                   10KW PEP / 5KW Average
Flatness...                                Better than +/- 5% from 1.8 to 30 MHz
                                                (+/- 3% typical from 1.8 to 30 MHz)
Directivity...                             >30dB from 1.8 to 30 MHz
Return Loss...                          >40dB from 1.8 to 30 MHz
